產品描述Product description
◆K2-2F系列是一款專用型的蹺板開關，也通稱船型開關、波形開關等，應用于各類電動工具和清潔器具，如：臺鋸、臺式砂輪機、干濕兩用吸塵器等，也同樣適用于各類家用電器、儀器及辦公設備等。
◆K2-2F series are one special type rocker switches, for used in power tools and cleaning appliances such as: Table Saws, Bench Grinders, Dry and Wet Vacuum Cleaners, etc. Also for used in all kinds of Home appliances, testing equipments and office equipments, etc.
產品特征Features
◆可選帶以下功能 Optional with the function as follows:
→雙極雙單擲 DPST (Double Pole Single Throw)
→雙極雙單擲點動 DPST momentary (Double Pole Single Throw)
技術數據Technical data
→機械耐久壽命 Mechanical life endurance≥5E4 / 1E5
→電氣耐久壽命 Electrical life endurance≥1E4 / 5E4
→最大沖擊電流 Max. Inrush current at 250V48A / 72A
→最大沖擊電流 Max. Inrush current at 125V48A / 96A
→接觸電阻 Contact resistance≤30m Ohm
→絕緣電阻 Insulation resistance≥7M Ohm
→基本介電強度 Dielectric strength of function1500V
→加強介電強度 Dielectric strength of reinforced3000V
→環境溫度 Ambient temperature0°C~105°C
→操動件溫度 Actuator temperature0°C~55°C
→阻燃等級 FlammabilityUL 94V-0
→防護等級 Protection typeIP40
→適用于II類防護器具 Suitable for appliances of protection class II
端子類型Terminals
◆輸入端/輸出端 Input side/Output side:
→插片端子 Plug-in terminals 6.3×0.8mm
→插片端子 Plug-in terminals 4.8×0.8mm
→焊接端子 Solder terminals
電氣參數和認證 Electric Rating and Certification
