產品描述Product description
◆K2-2S系列是一款標準型的蹺板開關，也通稱船型開關、波形開關等，有多重款式可以選擇，可選帶防護罩實現防塵防水，也有內部防塵結構來實現防塵防水，特別適用于各類直流大電流的電動工具、園林工具，如：充電式臺劇、充電式電動割草機、充電式高壓清洗機等，也可以適用于交流和直流電焊機等。
◆K2-2S series are one standard type rocker switches, optional many kinds of types, optional with Protection Cap for dustproof and waterproof, or with Inner Protection Structure for dustproof and waterproof, specially for used in DC high rated power tools and gardening tools such as: Cordless Bench Grinders, Cordless Electric Lawnmowers, Cordless Electric High Pressure Washers, etc. Also for used in AC or DC Electric Welder, etc.
產品特征Features
◆可選帶以下功能 Optional with the function as follows:
→雙極單擲 DPST (Double Pole Single Throw)
→雙極雙擲 DPDT (Double Pole Double Throw)
◆可選帶以下附件 Optional with the accessories as follows:
→防護罩 Protection Cap
→內部防護結構 Inner Protection Structure
→焊接帶端子導線 Soldering with leads and terminals
技術數據Technical data
→機械耐久壽命 Mechanical life endurance≥1E5
→電氣耐久壽命 Electrical life endurance≥1E4
→最大電流 Max. current at 250V30A
→最大電流 Max. current at 130Vd.c30A
→接觸電阻 Contact resistance≤30m Ohm
→絕緣電阻 Insulation resistance≥7M Ohm
→基本介電強度 Dielectric strength of function1500V
→加強介電強度 Dielectric strength of reinforced3000V
→環境溫度 Ambient temperature0°C~105°C
→操動件溫度 Actuator temperature0°C~55°C
→阻燃等級 FlammabilityUL 94V-0
→防護等級 Protection typeIP40
→適用于II類防護器具 Suitable for appliances of protection class II
端子類型Terminals
◆輸入端/輸出端 Input side/Output side:
→插片端子 Plug-in terminals 6.3×0.8mm
→焊接端子 Solder terminals 6.3×1.0mm
電氣參數和認證 Electric Rating and Certification
