KND3-A3

KND3蹺板開關

KND3 series Rocker Switches

產品描述Product description

KND3系列是一款通用型的蹺板開關,也通稱船型開關、波形開關等,一般應用于各類電吹風、熱風槍等。
KND3?series are one general type rocker switches, commonly for used in Hair Driers, Heat Guns, etc.

產品特征Features

◆可選不同的主體 Optional with different Body Types
◆可選多種不同的按鈕 Optional with different Button Types

技術數據Technical data

→機械耐久壽命 Mechanical life endurance≥1E5
→電氣耐久壽命 Electrical life endurance≥5E4
→最大沖擊電流 Max. Inrush current at 250V30A
→最大沖擊電流 Max. Inrush current at 250V36A
→接觸電阻 Contact resistance≤30m Ohm
→絕緣電阻 Insulation resistance≥7M Ohm
→基本介電強度 Dielectric strength of function1500V
→加強介電強度 Dielectric strength of reinforced3000V
→環境溫度 Ambient temperature0°C~85°C
→操動件溫度 Actuator temperature0°C~55°C
→阻燃等級 FlammabilityUL 94V-0
→防護等級 Protection typeIP40
→適用于II類防護器具 Suitable for appliances of protection class II

端子類型Terminals

◆輸入端/輸出端 Input side/Output side:
→焊接端子 Solder terminals

電氣參數和認證 Electric Rating and Certification
