產品描述Product description
◆MSA(DA7-6/1, DA7-6/2)系列是一款標準型的微動開關，用途極廣，適用于各類小功率交流和直流電動工具和園林工具，如：電動釘槍、電動噴槍、打草機、修枝機(也叫綠籬機、籬笆剪)等。
◆MSA(DA7-6/1, DA7-6/2)?series are one standard type micro switches, commonly for use in low rated AC and DC powe r-tools or gardening tools, such as Electric Tackers, Electric S prayers, Grass Trimmers, Hedge Trimmers, etc.
產品特征Features
◆可選帶以下功能 Optional with the function as follows:
→單極常開 SPNO (Single Pole Normally Open)
→單極常閉常開 SPCO (Single Pole Close and Open)
→單極常閉 SPNC (Single Pole Normally Close)
→雙極常開 DPNO (Double Pole Normally Open)
→雙極常閉常開 DPCO (Double Pole Close and Open)
→雙極常閉 DPNC (Double Pole Normally Close)
◆可選附帶以下附件 Optional with the accessories as follows:
→壓柄 Push Handle
技術數據Technical data
→機械耐久壽命 Mechanical life endurance≥1E5
→電氣耐久壽命 Electrical life endurance≥5E4
→最大沖擊電流 Max. Inrush current36A
→接觸電阻 Contact resistance≤30m Ohm
→絕緣電阻 Insulation resistance≥7M Ohm
→基本介電強度 Dielectric strength of function1500V
→加強介電強度 Dielectric strength of reinforced3000V
→環境溫度 Ambient temperature0°C~85°C
→阻燃等級 FlammabilityUL 94V-0
→防護等級 Protection typeIP40
→適用于II類防護器具 Suitable for appliances of protection class II
端子類型Terminals
◆COM, NO, NC端子 Terminals:
→插片端子 Plug-in terminals 4.8×0.6mm
→焊接端子 Solder terminals
電氣參數和認證 Electric Rating and Certification
