產品特征Features
◆可選附帶以下功能 Optional with the function as follows:
→單極常開 SPNO (Single Pole Normally Open)
→單極常閉 SPNC (Single Pole Normally Close)
→單極常閉常開 SPCO (Single Pole Close and Open)
→雙極常開 DPNO (Double Pole Normally Open)
→雙極常閉 SPNC (Double Pole Normally Close)
→雙極常閉常開 SPCO (Double Pole Close and Open)
→雙極常閉常開異步 SPCO?asynchronously?(Double Pole Close and Open?asynchronously)
→一極常開，另一極常閉 One Pole NO, the Other NC
→一極常開，另一極常閉常開 One Pole NO, the Other CO
◆可選附帶以下附件 Optional with the accessories as follows:
→壓柄 Push Handle
→密封圈 SealRing
技術數據Technical data
→機械耐久壽命 Mechanical life endurance≥5E4 / 1E5
→電氣耐久壽命 Electrical life endurance≥1E4 / 5E4
→最大沖擊電流 Max. Inrush current at 250V84A
→最大沖擊電流 Max. Inrush currentat 125V120A
→接觸電阻 Contact resistance≤30m Ohm
→絕緣電阻 Insulation resistance≥7M Ohm
→基本介電強度 Dielectric strength of function500V / 1500V
→加強介電強度 Dielectric strength of reinforced500V /?3000V
→環(huán)境溫度 Ambient temperature0°C~55°C
→環(huán)境溫度 Ambient temperature-25°C~125°C
→阻燃等級 FlammabilityUL 94V-0
→防護等級 Protection typeIP40
→適用于II類防護器具 Suitable for appliances of protection class II
→開關操作力選擇范圍 Operating force range3N~15N
→開關內部觸點間隙 Contact gap?range0.8~3.0mm
端子類型Terminals
◆COM, NO, NC端子 Terminals:
→插片端子 Plug-in terminals 6.3×0.8mm
→插片端子 Plug-in terminals 4.8×0.8mm
→插片端子 Plug-in terminals 4.8×0.5mm
→焊接端子 Solder terminals
→線路板焊接端子 PCB Solder terminals
★本產品榮獲多項實用新型專利，專利號：ZL201921788022.3，ZL201920465989.1
★Utility Models patented with the no. is?ZL201921788022.3,?ZL201920465989.1
