產品描述Product description
◆MSB系列是一款標準型的微動開關，有微斷開(1mm)、2.5mm和3.0mm觸點間隙可以選擇，用途極廣，可用于各類電動工具和園林工具，如：型材切割機、斜切鋸、高壓清洗機、打草機、修枝剪、電鏈鋸、電動螺絲刀、電動釘槍、電動噴槍、腳踏開關等，也可應用于各類家用電器及辦公設備，如：碎紙機、微波爐、水泵浮球開關、游戲搖桿、門開關等。
◆MSB?series are one standard micro switches, optional micro contact gap?(1mm), 2.5mm?and 3.0mm contact gap, commonly for used in all kinds of power-tools and gardening tools, such as Cut-off Machines, Miter Saws, Electric Chain Saws, Grass Trimmers, Hedge Trimmers, Electric Screw Drivers, Electric Nailers, Electric Sprayers, High Pressure Washers, etc. Also for used in home appliances and office equipments, such as Paper Shredders, Microwave Ovens, Pumps Ball Cock Switches, Game Control Handles, Door Switches, etc.
產品特征Features
◆可選附帶以下功能 Optional with the function as follows:
→單極常開 SPNO (Single Pole Normally Open)
→單極常閉 SPNC (Single Pole Normally Close)
→單極常閉常開 SPCO (Single Pole Close and Open)
→雙極常開 DPNO (Double Pole Normally Open)
→雙極常閉 SPNC (Double Pole Normally Close)
→雙極常閉常開 SPCO (Double Pole Close and Open)
→雙極常閉常開異步 SPCO asynchronously (Double Pole Close and Open asynchronously)
→一極常開，另一極常閉 One Pole NO, the Other NC
→一極常開，另一極常閉常開 One Pole NO, the Other CO
◆可選附帶以下附件 Optional with the accessories as follows:
→壓柄 Push Handle
→密封圈 SealRing
技術數據Technical data
→機械耐久壽命 Mechanical life endurance≥5E4 / 1E5
→電氣耐久壽命 Electrical life endurance≥1E4 / 5E4
→最大沖擊電流 Max. Inrush current at 250V84A
→最大沖擊電流 Max. Inrush currentat 125V120A
→接觸電阻 Contact resistance≤30m Ohm
→絕緣電阻 Insulation resistance≥7M Ohm
→基本介電強度 Dielectric strength of function500V / 1500V
→加強介電強度 Dielectric strength of reinforced500V /?3000V
→環境溫度 Ambient temperature0°C~55°C
→環境溫度 Ambient temperature-25°C~125°C
→阻燃等級 FlammabilityUL 94V-0
→防護等級 Protection typeIP40
→適用于II類防護器具 Suitable for appliances of protection class II
→開關操作力選擇范圍 Operatingforcerange3N~15N
→開關內部觸點間隙 Contactgaprange0.8~3.0mm
端子類型Terminals
◆COM, NO, NC端子 Terminals:
→插片端子 Plug-in terminals 6.3×0.8mm
→插片端子 Plug-in terminals 4.8×0.8mm
→插片端子 Plug-in terminals 4.8×0.5mm
→焊接端子 Solder terminals
→線路板焊接端子 PCB Solder terminals
★本產品榮獲多項實用新型專利，專利號：ZL201921788022.3，ZL201920465989.1
★Utility Models patented with the no. is?ZL201921788022.3,?ZL201920465989.1
電氣參數和認證 Electric Rating and Certification
