產品描述Product description
◆MSE系列是一-款專用型的微動開關，裝上防塵罩后具有防塵功能，適用于各類手持電動工具和園林工具，如：砂光機、拋光機、100和125角磨機、小圓鋸、小型斜切鋸(介鋁機)、電動噴槍、打草機，電鏈鋸等。
◆ MSE series are one special type micro switches, with dustproof function when employ protection cap, commonly for used in portable power-tools and gardening tools, such as Sanders,Polisher Grinders, 100mm and 125mm Small Angle Grinders,Small Circular Saws, Small Miter Saws, Electric Sprayers, Grass Trimmers, Electric Chain Saws, etc.
產品特征Features
◆可選附帶以下功能 Optional with the function as follows:
→單極常開 SPNO (Single Pole Normally Open)
→單極常閉 SPNC (Single Pole Normally Close)
→單極常閉常開 SPCO (Single Pole Close and Open)
→雙極常開 DPNO (Double Pole Normally Open)
→雙極常閉 SPNC (Double Pole Normally Close)
→雙極常閉常開 SPCO (Double Pole Close and Open)
◆可選附帶以下附件 Optional with the accessories as follows:
→壓柄 Handle
→防護罩 Protection Cap
技術數據Technical data
→機械耐久壽命 Mechanical life endurance≥5E4/1E5
→電氣耐久壽命 Electrical life endurance≥1E4/5E4
→最大沖擊電流 Max. Inrush current at 250V60A
→最大沖擊電流 Max. Inrush current at 127V96A
→接觸電阻 Contact resistance≤30m Ohm
→絕緣電阻 Insulation resistance≥7M Ohm
→基本介電強度 Dielectric strength of function1500V
→加強介電強度 Dielectric strength of reinforced3000V
→環境溫度 Ambient temperature (ENEC/UL)-25°C~125C
→環境溫度 Ambient temperature (TOV/ CQC)0°C~85°C
→阻燃等級 FlammabilityUL 94V-0
→防護等級 Protection typeIP60
→適用于II類防護器具 Suitable for appliances of protection class II
→開關操作力選擇范圍 Operating force range3N~15N
→開關內部觸點間隙Contact gap range0.8~2.5mm
端子類型Terminals
◆COM, NO, NC端子 Terminals:
→插片端子 Plug-in terminals 4.8×0.8mm
→插片端子 Plug-in terminals 4.8×0.5mm
→焊接端子 Solder terminals
★本產品榮獲實用新型專利，專利號：ZL201920124632.7
★Utility Model patented with the no. is ZL201920124632.7
電氣參數和認證 Electric Rating and Certification
