產品描述Product description
◆JB01系列是一款大電流的安全限位開關，集成防塵防水功能，JB010B為迷你款，適用于各類臺式電動工具和園林工具，如：臺式推拉鋸、臺式圓鋸、臺式刨床、臺式銑床、臺式車床、臺式線鋸、臺式鉆床和家用碎枝機等。
◆JB01 series are high rated safety limited switches, integrated dustproof and waterproof, JB010B is mini-type, for used in bench top power-tools or gardening tools, such as Bench Push-pull Saws, Bench Circular Saws, Bench Planers, Bench Routers, Bench Lathes, Bench Scroll Saws, Bench Drill Presses, Domestic Shredders, etc.
產品特征Features
◆可選帶以下功能 Optional with the function as follows:
→雙極常開?DPNO?(Double Pole Normally Open)
→雙極常閉?DPNC?(Double Pole Normally Close)
◆可選帶以下附件 Optional with the accessories as follows:
→鑰匙扣 Key
→門控制桿 Handle for door
技術數據Technical data
→機械耐久壽命 Mechanical life endurance≥5E4 / 1E5
→電氣耐久壽命 Electrical life endurance≥1E4 / 5E4
→最大沖擊電流 Max. Inrush current at 250V90A
→接觸電阻 Contact resistance≤30m Ohm
→絕緣電阻 Insulation resistance≥7M Ohm
→基本介電強度 Dielectric strength of function1500V
→加強介電強度 Dielectric strength of reinforced3000V
→環境溫度 Ambient temperature0°C~55°C
→阻燃等級 FlammabilityUL 94V-0
→防護等級 Protection typeIP54 Max.
→適用于II類防護器具 Suitable for appliances of protection class II
端子類型Terminals
◆JB01輸入端/輸出端 Input side/Output side of JB01:
→螺釘端子 Screw terminals M4
◆JB01B輸入端/輸出端 Input side/Output side of JB01B:
→插片端子 Plug-in terminals 4.8×4.8mm
電氣參數和認證 Electric Rating and Certification
