產品描述Product description
◆JB03系列是一款標準型的電磁開關，安裝防護罩后集成防塵防水功能，適合各類臺式電動工具和園林工具，如：臺式推拉鋸、臺式圓鋸、臺式刨床、臺式銑床、臺式車床、臺式線鋸、臺式鉆床、臺式砂輪機和家用碎枝機等。
◆JB03 series are one standard electromagnetism switches, integrated dustproof and waterproof when employ Protection Cap, for use in bench top power-tools and gardening tools such as: Bench Push-pull Saws, Bench Circular Saws, Bench Planers, Bench Routers, Bench Lathes, Bench Scroll Saws, Bench Drill Presses, Bench Grinders, Domestic Shredders, etc.
產品特征Features
◆可選帶以下附件 Optional with the accessories as follows:
→兒童安全鎖 Lock for children's safety
→線圈外接端子 Terminal of winding outside
→急停蓋 Emergency stop cover
技術數據Technical data
→機械耐久壽命 Mechanical life endurance1E5
→電氣耐久壽命 Electrical life endurance5E4
→最大沖擊電流 Max. Inrush current at 250V84A
→最大沖擊電流 Max. Inrush current at 125V96A
→接觸電阻 Contact resistance≤30m Ohm
→絕緣電阻 Insulation resistance≥7M Ohm
→基本介電強度 Dielectric strength of function1500V
→加強介電強度 Dielectric strength of reinforced3000V
→環境溫度 Ambient temperature0°C~85°C
→操動件溫度 Actuator temperature0°C~55°C
→阻燃等級 FlammabilityUL 94V-0
→防護等級 Protection typeIP55 Max.
→適用于II類防護器具 Suitable for appliances of protection class II
端子類型Terminals
◆輸入端/輸出端 Input side/Output side:
→插片端子 Plug-in terminals 6.3×0.8mm
◆線圈外接插片端子 Terminal of winding:
→插片端子 Plug-in terminals 2.8×0.8mm
電氣參數和認證 Electric Rating and Certification
