產品特征Features
◆可選帶以下功能 Optional with the function as follows:
→雙極常開 DPNO (Double Pole Normally Open)
→一極常閉，另一極常開 One Pole Normally Close, the other Normally Open
→一極常閉，另二極常開 One Pole Normally Close, the other two poles Normally Open
技術數據Technical data
→機械耐久壽命 Mechanical life endurance≥5E4/1E5
→電氣耐久壽命 Electrical life endurance≥1E4/5E4
→最大沖擊電流 Max. Inrush current at 250V96A
→最大沖擊電流 Max. Inrush currentat 125V120A
→接觸電阻 Contact resistance≤30m Ohm
→絕緣電阻 Insulation resistance≥7M Ohm
→基本介電強度 Dielectric strength of function1500V
→加強介電強度 Dielectric strength of reinforced3000V
→環境溫度 Ambient temperature0°C~55°C
→阻燃等級 FlammabilityUL 94V-0
→防護等級 Protection typeIP40
→適用于II類防護器具 Suitable for appliances of protection class II
端子類型Terminals
◆輸入端/輸出端 Input side/Output side:
→插片端子 Plug-in terminals 6.3×0.8mm
