產品描述Product description
◆RSA, RSB, RSC系列是一款通用型的旋轉開關，廣泛應用于各類需要檔位選擇的家用電器，如：電燉鍋、食物攪拌機、榨汁機、豆?jié){機、吸塵器、電風扇、空調扇、臺燈等。開關有多種轉軸和外殼可以選擇，也可以根據客戶要求進行定制，也可以應用于一些特殊的電動工具和園林工具，如：熱風槍、吹風機等。
◆RSA, RSB, RSC series are general type rotary switches, for popular used in home appliances such as: Slower Cookers, Food Mixers, Full Automatic Soya-bean Milk Machines, Juicers, Vacuum Cleaner, Electric Fan, Air Condition Fan, Table Lamps, etc. Also for used in some special Power-tools and Gardening tools, such as: Heat Guns, Electric Blowers, etc.
產品特征Features
◆可選帶以下功能 Optional with function as follows:
→單極兩檔位 Single Pole 2 Position
→單極三檔位 Single Pole 3 Position
→單極四檔位 Single Pole 4 Position
→單極五檔位 Single Pole 5 Position
技術數據Technical data
→機械耐久壽命 Mechanical life endurance≥5E4
→電氣耐久壽命 Electrical life endurance≥1E4
→最大沖擊電流 Max. Inrush current at 250V18A
→最大沖擊電流 Max. Inrush current at 125V18A
→接觸電阻 Contact resistance≤30m Ohm
→絕緣電阻 Insulation resistance≥7M Ohm
→基本介電強度 Dielectric strength of function1500V
→加強介電強度 Dielectric strength of reinforced3000V
→環境溫度 Ambient temperature0°C~125°C
→阻燃等級 FlammabilityUL 94V-0
→防護等級 Protection typeIP40
→適用于II類防護器具 Suitable for appliances of protection class II
端子類型Terminals
◆輸入端/輸出端 Input side/Output side:
→4×插入式端子可插入沾錫導線、帶插片端子導線或銅包頭導線
→4×Push-in terminals for soldered strands, strands with end sleeves or strands with end claws.
電氣參數和認證 Electric Rating and Certification
