BC-02

BC電池夾

BC series Battery Clamp

產品描述Product description

BC系列是專用型的直流電池夾,應用于各類直流電池式手持電動工具,如:充電式電鉆、充電式螺絲起子等,可按照各類要求進行定制。
BC series are special type DC battery clamp, for used in DC cordless portable power-tools such as: Cordless Drills, Cordless Screw Drivers, etc. We can make customized according to different request.

產品特征Features

◆材料:錫青銅 Material: Tin-bronze
◆表面處理:鍍鎳 surface treatment: Nickel Plated

技術數據Technical data

→機械耐久壽命 Mechanical life endurance

≥1E4→最大電流 Max. current at 42Vd.c25A
→接觸電阻 Contact resistance≤30m Ohm

→環境溫度 Ambient temperature0°C~55°C
→阻燃等級 FlammabilityUL 94V-0

端子類型Terminals

◆輸入端 Input side:
→焊接端子 Soldering terminal

電氣參數和認證 Electric Rating and Certification
