產品描述Product description
◆MK07系列是一款專用型線路板組件,具有軟啟動,恒轉速等功能,廣泛應用于各類手持式電動工具,如: 150和180角向磨光機，拋光機等.
◆MK07 series are one special type PCB Assembly, with soft start function and Constant Speed function, etc. Commonly for used in portable power-tools such as 150mm and 180mm Angle Grinders, Polisher Grinders, etc.
產品特征Features
◆可選帶以下功能Optional following function types:
→斷電重啟保護功能Restart Protection(X)
→電子調速功能Electronics Speed Control Function(E)
→軟啟動功能Soft Start Function(S)
→恒轉速功能Constant Speed function(CS)
→恒功功能Constant Power Function(P)
→過流保護功能Over Current Protection Function(CP)
技術數據Technical data
→電氣耐久壽命Electrical life endurance≥5E4
→最大電流Max. current at 250V12A
→最大電流Max. current at 127V18A
→絕緣電阻Insulation resistance≥7M Ohm
→基本介電強度Dielectric strength of function500V
→加強介電強度Dielectric strength of reinforced3000V
→環境溫度Ambient temperature0°C~55°C
→阻燃等級FlammabilityUL 94V-0
→適用于II類防護器具Suitable for appliances of protection class II
端子類型Terminals
◆輸入端/輸出端Input side/Output side:
→導線端子Wire lead terminals
→信號端-帶插頭導線Single-Wire lead terminals with plug
電氣參數和認證 Electric Rating and Certification
