產品特征Features
◆可選帶以下功能 Optional with following function:
→全波調速 Full-wave speed control
→半波調速 Half-wave speed control
→On-Off通斷功能 On-Off version
◆可選帶以下鎖定類型 Optional with following lock types:
→無鎖 No Lock
→閉合鎖定 Lock-on
技術數據Technical data
→機械耐久壽命 Mechanical life endurance≥1E5
→電氣耐久壽命 Electrical life endurance≥5E4
→最大沖擊電流 Max.Inrush current at 250V48A
→最大沖擊電流 Max.Inrush current at 127V60A
→接觸電阻 Contact resistance≤30m Ohm
→絕緣電阻 Insulation resistance≥7M Ohm
→基本介電強度 Dielectric strength of function1500V
→加強介電強度 Dielectric strength of reinforced3000V
→環境溫度 Ambient temperature0°C~55°C
→阻燃等級 FlammabilityUL 94V-0
→防護等級 Protection typeIP40
→開關內部電子部分在相應使用中一并做過相關測試，本開關適合做二類器具開關使用.
→The electronics in the switches are to be tested together with the corresponding appliance, the switches are suitable for appliance of class II.
端子類型Terminals
◆輸入端 Input side:
→接線柱端子孔徑=3mm Pillar terminals φ =3mm
◆輸出端 Output side:
→插入式端子可插入沾錫導線,帶插片端子導線或銅包頭導線
→Push-in terminals for soldered strands, strands with end claws
◆換向盒端 Reversing Box side:
→插片端子 Plug-in terminal 2.8X0.8mm
★ 本產品榮獲實用新型專利，專利號：ZL201920483843.X
★ Utility Model patented with no. is ZL201920483843.X
