FA5-3E-A3N

FA5-3E交流扳機調速開關

FA5-3E series AC Variable Speed (Trigger) Switches

產品描述Product description

FA5-3E系列是一款通用型扳機電子調速開關,廣泛應用于各類小型手持式電動工具,如:電鉆、電錘、曲線鋸、腳踏調速開關等。
FA5-3E series are one general type variable speed trigger switches with by-pass contact, for popular used in portable power-tools such as: Electric Drills, Rotary Hammers, Jig Saws, Foot Variable Speed Switches, etc.

產品特征Features

◆可選帶以下功能 Optional with following function:
→全波調速 Ful-wave speed control
→半波調速 Half- wave speed control
→三檔位調速功能 Three Shift Variable Speed Function
◆可選帶以下鎖定類型 Optional with following lock types:
→無鎖 No Lock
→閉合鎖定 Lock-on
◆可選帶以下附件 Optional with the accessories as follows:
→初始電壓微調節旋鈕 Knob for adjusting start voltage

技術數據Technical data

→機械耐久壽命 Mechanical life endurance≥1E5
→電氣耐久壽命 Electrical life endurance≥5E4
→最大沖擊電流 Max. Inrush current at 250V36A
→最大沖擊電流 Max. Inrush current at 125V48A
→接觸電阻 Contact resistance≤30m Ohm
→絕緣電阻 Insulation resistance≥100M Ohm
→基本介電強度 Dielectric strength of function1500V
→加強介電強度 Dielectric strength of reinforced3000V
→環境溫度 Ambient temperature0°C~55°C
→阻燃等級 FlammabilityUL 94V-0
→防護等級 Protection typeIP40
→開關內部電子部分在相應使用中一并做過相關測試,本開關適合做二類器具開關使用。
→The electronics in the switches are to be tested together with the corresponding appliance, the switches are suitable for appliance of class?II.

端子類型Terminals

◆輸入端 Input side:
→接線柱端子 Pillar terminals φ=3mm
◆輸出端 Output side:
→插入式端子可插入沾錫導線,帶插片端子導線或銅包頭導線
→Push-in terminals for soldered strands, strands with end sleeve or strands with end claws

電氣參數和認證 Electric Rating and Certification

訂貨信息Ordering Information
