產品描述Product description
◆FA5-3S/FA5-6S 系列是一款通用型扳機電子調速開關，其中FA5-6S系列是升級款，可以承受更大的電流沖擊，集成防塵功能，廣泛應用于各類電動工具，如: 6mm電鉆、10mm電鉆、沖擊鉆、沖擊螺絲起子、電錘、曲線鋸、攪拌器、平板砂光機等, 也可用于吊磨機的腳踏開關等。開關有多種扳機、鎖鈕和撥桿可以選擇，也可以根據客戶要求進行定制。
◆FA5-3S/FA5-6S series are one general type variable speed trigger switches with by-pass contact, specially FA5-6S is high rated type, integrated dustproof, for popular used in portable power-tools such as: 6mm Drills, 10mm Drills, Impact Drills, Impact Screw Drivers, Rotary Hammers, Jig Saws, Electric Mixers, Orbit Sanders, etc. Also used for Foot switch of Hanging Carving Machine.
產品特征Features
◆可選帶以下功能 Optional with following functions:
→全波調速 Full-wave speed control
→半波調速 Half-wave speed control
→On-Off通斷功能 On-Off version
→On-Off通斷功能帶線性電位器輸出 On-off version with Passive linear potentiometer
→正轉或反轉限速 Speed limited in forward or reverse
◆可選帶以下鎖定類型 Optional with following lock types:
→無鎖 No Lock
→閉合鎖定 Lock-on
◆可選帶以下附件 Optional with the accessories as follows:
→初始電壓微調節旋鈕 Knob for adjusting start voltage
→扳機旋鈕 Dial wheel of Trigger
→包軟膠扳機 Trigger covered with rubber (overmolding)
◆開關內部電子部分在相應使用中一并做過相關測試，本開關適合做二類器具開關使用.
◆The electronics in the switches are to be tested together with the corresponding appliance, the switches are suitable for appliance of class II.
端子類型Terminals
◆輸入端 Input side:
→接線柱端子 Pillar terminals φ=3mm
◆輸出端和換向盒端 Output side and Reversing Box side:
→插入式端子可插入沾錫導線，帶插片端子導線或銅包頭導線
→Push-in terminals for soldered strands, strands with end sleeve or strands with end claws.
★本產品榮獲實用新型專利，專利號：ZL201920465988.7
★Utility Model patented with the no. is ZL201920465988.7
電氣參數和認證 Electric Rating and Certification
