◆DR2-6E系列是一款通用型的轉盤電子調速器，是FR-6E系列的迷你版本，應用于各類手持電動工具，如：電錘、曲線鋸、往復鋸、100和125角向磨光機、,拋光機、攪拌器、電木銑、砂光機、模具電磨等。
◆DR2-6E series are one general type AC Dial Wheel Speed Controls, the mini-type of FR-6E series, for popular used in portable power-tools such as: Rotary Hammer, Jig Saws, Reciprocating Saws, 100mm and 125mm Angle Grinders, Polisher Grinders, Electric Routers, Sanders, Die Grinders, etc.◆可選帶以下功能 Optional with following function:
→全波調速 Full-wave s peed control
→半波調速 Half-wave speed control
→On-Off通斷功能帶可變電阻輸出 On-off version with Passive linear potentiometer
◆可選帶以下附件 Optional with the accessories as follows:
→初始電壓微調節旋鈕 Knob for adjusting start voltage
→可控硅外置適合更大電流并可附帶散熱片
→External Triac version for high currents additional with heat sink
→機械耐久壽命 Mechanical life endurance≥1E5
→電氣耐久壽命 Electrical lifeendurance≥5E4
→最大電流 Max. current at 250V8A
→最大電流 Max. current at 125V12A
→接觸電阻 Contact resistance≤30m Ohm
→絕緣電阻 Insulation resistance≥7M Ohm
→基本介電強度 Dielectric strength of function500V
→加強介電強度 Dielectric strength of reinforced3000V
→環境溫度 Ambient temperature0°C~55°C
→阻燃等級 Flammability UL 94V-0
→防護等級 Protection type IP40
→開關內部電子部分在相應使用中一并做過相關測試，本開關適合做二類器具開關使用。
→The electronics in the switches are to be tested together with the corresponding appliance, the switches are suitable for appliance of class II.
◆輸入端/輸出端 Input side/Output side:
→導線端子 Wires terminals AWG14 ~ AWG18.
