DR2-6E-1612E-C1-S3-X120

DR2-6E交流轉盤調速器

DR2-6E series AC Dial Wheel Speed Controls

產品描述Product description

DR2-6E系列是一款通用型的轉盤電子調速器,是FR-6E系列的迷你版本,應用于各類手持電動工具,如:電錘、曲線鋸、往復鋸、100和125角向磨光機、,拋光機、攪拌器、電木銑、砂光機、模具電磨等。

DR2-6E series are one general type AC Dial Wheel Speed Controls, the mini-type of FR-6E series, for popular used in portable power-tools such as: Rotary Hammer, Jig Saws, Reciprocating Saws, 100mm and 125mm Angle Grinders, Polisher Grinders, Electric Routers, Sanders, Die Grinders, etc.

產品特征Features

◆可選帶以下功能 Optional with following function:

→全波調速 Full-wave s peed control

→半波調速 Half-wave speed control

→On-Off通斷功能帶可變電阻輸出 On-off version with Passive linear potentiometer

◆可選帶以下附件 Optional with the accessories as follows:

→初始電壓微調節旋鈕 Knob for adjusting start voltage

→可控硅外置適合更大電流并可附帶散熱片

→External Triac version for high currents additional with heat sink

技術數據Technical data

→機械耐久壽命 Mechanical life endurance

≥1E5

→電氣耐久壽命 Electrical lifeendurance≥5E4

→最大電流 Max. current at 250V8A

→最大電流 Max. current at 125V12A

→接觸電阻 Contact resistance≤30m Ohm

→絕緣電阻 Insulation resistance≥7M Ohm

→基本介電強度 Dielectric strength of function500V

→加強介電強度 Dielectric strength of reinforced3000V

→環境溫度 Ambient temperature0°C~55°C

→阻燃等級 FlammabilityUL 94V-0

→防護等級 Protection typeIP40

→開關內部電子部分在相應使用中一并做過相關測試,本開關適合做二類器具開關使用。

→The electronics in the switches are to be tested together with the corresponding appliance, the switches are suitable for appliance of class II.

端子類型Terminals

◆輸入端/輸出端 Input side/Output side:

→導線端子 Wires terminals AWG14 ~ AWG18.

電氣參數和認證 Electric Rating and Certification

訂貨信息Ordering Information
