◆FR-6E系列是一款通用型的轉盤電子調速器，集成一般防塵功能，應用于各類手持電動工具，如：電錘、曲線鋸、往復鋸、拋光機、攪拌器、電木銑、砂光機、100、125和150角向磨光機、模具電磨等。
◆FR-6E series are one general type AC Dial Wheel Speed Controls, integrated dustproof, for popular used in portable power-tools such as: Rotary Hammers, Jig Saws, Reciprocating Saws, Polisher Grinders, Electric Mixers, Electric Routers,Sanders, 100~150mm Angle Grinders, Die Grinders, etc.
◆可選帶以下功能 Optional with following function:
→全波調速 Full-wave speed control
→半波調速 Half-wave speed control
→On-Off通斷功能帶可變電阻輸出 On-off version with Passive linear potentiometer
→帶可變電阻輸出 with Passive linear potentiometer
◆可選帶以下附件 Optional with the accessories as follows:
→初始電壓微調節旋鈕 Knob for adjusting start voltage
→可控硅外置適合更大電流并可附帶散熱片
→External Triac version for high currents additional with heat sink
▲可選轉盤一檔印字與殼體上表面成67.5°
▲Optional the angle between the printing of 1 and the up surface of shell is 67.5
■可選轉盤一檔印字與殼體上表面成90°
■Optional the angle between the printing of 1 and the up surface of shellis 90°
◆輸入端/輸出端 Input side/Output side:
→插入式端子可插入沾錫導線、帶插片端子導線或銅包頭導線
→Push-in terminals for soldered strands, strands with end sleeves or strands with end claws
