FR-6E-E-X

FR-6E交流轉盤調速器

FR-6E series AC Dial Wheel Speed Controls

產品描述Product description

◆FR-6E系列是一款通用型的轉盤電子調速器，集成一般防塵功能，應用于各類手持電動工具，如：電錘、曲線鋸、往復鋸、拋光機、攪拌器、電木銑、砂光機、100、125和150角向磨光機、模具電磨等。

◆FR-6E series are one general type AC Dial Wheel Speed Controls, integrated dustproof, for popular used in portable power-tools such as: Rotary Hammers, Jig Saws, Reciprocating Saws, Polisher Grinders, Electric Mixers, Electric Routers,Sanders, 100~150mm Angle Grinders, Die Grinders, etc.

產品特征Features

◆可選帶以下功能 Optional with following function:
→全波調速 Full-wave speed control
→半波調速 Half-wave speed control
→On-Off通斷功能帶可變電阻輸出 On-off version with Passive linear potentiometer
→帶可變電阻輸出 with Passive linear potentiometer
◆可選帶以下附件 Optional with the accessories as follows:
→初始電壓微調節旋鈕 Knob for adjusting start voltage
→可控硅外置適合更大電流并可附帶散熱片
→External Triac version for high currents additional with heat sink
▲可選轉盤一檔印字與殼體上表面成67.5°
▲Optional the angle between the printing of 1 and the up surface of shell is 67.5
■可選轉盤一檔印字與殼體上表面成90°
■Optional the angle between the printing of 1 and the up surface of shellis 90°

技術數據Technical data

→機械耐久壽命 Mechanical life endurance≥1E5
→電氣耐久壽命 Electrical life endurance≥5E4
→最大電流 Max. current at 250V10A
→最大電流 Max. current at 125V16A
→接觸電阻 Contact resistance≤30m Ohm
→絕緣電阻 Insulation resistance≥7M Ohm
→基本介電強度 Dielectric strength of function500V
→加強介電強度 Dielectric strength of reinforced3000V
→環境溫度 Ambient temperature0°C~55°C
→阻燃等級 FlammabilityUL 94V-0
→防護等級 Protection typeIP40
→開關內部電子部分在相應使用中一并做過相關測試，本開關適合做二類器具開關使用.
→The electronics in the switches are to be tested together with the corresponding appliance, the switches are suitable for appliance of class II.

端子類型Terminals

◆輸入端/輸出端 Input side/Output side:

→插入式端子可插入沾錫導線、帶插片端子導線或銅包頭導線

→Push-in terminals for soldered strands, strands with end sleeves or strands with end claws

產品描述

Product description

產品特征

Features

技術數據

Technical data

端子類型

Terminals

電氣參數和認證

Electric Rating and Certification

訂貨信息
