DEK-E-A13

DEK防塵（智能）直流扳機調速開關

DEK series Dustproof (Multi-function) DC Variable Speed Trigger Switches

產品描述Product description

◆DEK系列是一款通用型的直流扳機調速開關，集成防塵和機械剎車接點，內部帶換向結構，應用于各類直流充電式手持電動工具，如:充電式電鉆、充電式電錘、充電式螺絲起子、充電式?jīng)_擊扳手等.
◆DEK series are one general type DC variable speed trigger switches, integrated dustproof, mechanical brake contact and reversing box, commonly for used in DC cordless portable power-tools such as: Cordless Drills, Cordless Screw Drivers, Cordless Rotary Hammers, Cordless Impact Wrenches, etc.

產品特征Features

◆本開關結構緊湊效率高,大面積的固定式散熱片為開關的安裝提供方便.開關內部為單極常開帶直通接點結構,通過改變輸入脈沖的占空比來控制場效應管的輸出電壓，而實現電子調速功能.
◆開關輸出端的平均電壓為總電壓的8-50%至8-90%,也可以按客戶要求進行定制,開關按到底由直通接點接至電池端電壓.
◆可選帶以下功能或附件:
→外置MOS管
→帶軟膠扳機
→外接LED及導線
→外接電池溫度檢測導線
→智能調速功能,可帶軟啟動,欠壓保護,過流保護,電池過溫保護
◆The switches combine compact size with high performance, a wide scope of heat sink for MOSFET and further options provide easy to mount solutions. They employ SPST-NO with by-pass contact, integrated PWM (Pulse Width Modulated) electronics in
various dimensions.
◆Average duty cycle of motor voltage 8 - 50% to 8 - 99%, then by-pass to battery voltage (according to customer's demand).
◆Optional with the function or accessory as follows:

→External MOSFET version

→Trigger covered with rubber

→Auxiliary LED and wires

→Auxiliary wire for temperature test

→Multi-function, optional soft start, under-voltage protection, over current protection, battery temperature protection

技術數據Technical data

→機械耐久壽命 Mechanical life endurance≥1E5
→電氣耐久壽命 Electrical life endurance≥5E4
→最大電流 Max. current at 42Vd.c25A
→接觸電阻 Contact resistance≤30m Ohm
→絕緣電阻 Insulation resistance≥7M Ohm
→基本介電強度 Dielectric strength of function500V
→加強介電強度 Dielectric strength of reinforced500V
→環境溫度 Ambient temperature0°C~55°C
→阻燃等級 FlammabilityUL 94V-0
→防護等級 Protection typeIP40
◆開關內部電子部分在相應使用中一并做過相關測試,本開關適合做二類器具開關使用.
◆The electronics in the switches had to be tested together with the corresponding appliances, so the switches are suitable for appliance of class II.
