產品特征Features
◆本開關結構緊湊效率高,大面積的固定式散熱片為開關的安裝提供方便.開關內部為單極常開帶直通接點結構,通過改變輸入脈沖的占空比來控制場效應管的輸出電壓,而實現電子調速功能.
◆開關輸出端的平均電壓為總電壓的8- 50%至8- 90%,也可以按客戶要求進行定制,開關按到底由直通接點接至電池端電壓.
◆可選帶以下功能或附件:
→外置MOS管
→帶軟膠扳機
→外接發光LED及導線
→外接電池溫度檢測導線
→智能調速功能,可帶軟啟動,欠壓保護,過流保護,電池過溫保護
◆The switches combine compact size with high performance, a wide scope of heat sink for MOSFET and further options provide easy to mount solutions. They employ SPST-NO with by-pass contact, integrated PWM (Pulse Width Modulated) electronics in
various dimensions.
◆Average duty cycle ofmotorvoltage8-50%to8-90% (according to client's demand), then by-pass to battery voltage.
◆Optional with the function or accessory as follows:
→External MOSFET version
→Trigger covered with rubber
→Auxiliary LED and wires
→Auxiliary wire for temperature test
→Multi-function, optional soft start, under-voltage protection, over current protection, battery temperature pretection
技術數據Technical data
→機械耐久壽命 Mechanical life endurance≥1E5
→電氣耐久壽命 Electrical life endurance≥5E4
→最大電流 Max. current at 42Vd.c25A
→接觸電阻 Contact resistance≤30m Ohm
→絕緣電阻 Insulation resistance≥7M Ohm
→基本介電強度 Dielectric strength of function500V
→加強介電強度 Dielectric strength of reinforced500V
→環境溫度 Ambient temperature0°C~55°C
→阻燃等級 FlammabilityUL 94V-0
→防護等級 Protection typeIP40
→適用于II類防護器具 Suitable for appliances of protection class II
◆開關內部電子部分在相應使用中一并做過相關測試，本開關適合做二類器具開關使用.
◆The electronics in the switches are to be tested together with the corresponding appliance, the switches are suitable for appliance of class II.
端子類型Terminals
◆輸入端/輸出端Input side/Output side:
→焊接端子Solder terminal
