產品特征Features
◆本開關結構緊湊，可選帶以下功能或附件：
→電子調速功能
→智能調速功能，可選帶軟啟動、欠壓保護、過流保護、電池過溫保護等
→外接各類導線和電池夾
◆The switches combine compact size, optional with the function or accessories as follows:
→Electronics variable speed control function
→Multi-function, optional soft start, under-voltage protection, over current protection, battery temperature protection, etc.
→Auxiliary wire or battery clamp
技術數據Technical data
→機械耐久壽命 Mechanical life endurance≥5E4/1E5
→電氣耐久壽命 Electrical life endurance≥1E4/5E4
→最大電流 Max. currentat 18Vd.c20A
→接觸電阻 Contact resistance≤30m Ohm
→絕緣電阻 Insulation resistance≥7MOhm
→基本介電強度 Dielectric strength of function500V
→加強介電強度 Dielectric strength of reinforced500V
→環境溫度 Ambient temperature0°C~55°C
→阻燃等級 FlammabilityUL 94V-0
→防護等級 Protection typeIP40
◆開關內部電子部分在相應使用中一并做過相關測試,本開關適合做二類器具開關使用.
◆The electronics in the switches had to be tested together with the corresponding appliances, so the switches are suitable for appliance of class II.
端子類型Terminals
◆輸入端 Input side:
→焊接端子 Solder terminal 4.2×0.8mm
◆輸出端 Output side:
→焊接端子 Solder terminal4.6×0.5mm
