產品描述Product description
◆DPK-S系列是一款通用型的直流信號扳機開關，集成防塵功能，內部帶換向結構，特別應用于各類直流無刷充電式手持電動工具和園林工具，如：無刷充電式電鉆、無刷充電式電錘、無刷充電式螺絲起子、無刷充電式?jīng)_擊扳手、無刷充電式打草機、無刷充電式吹風機等。
◆DPK-S?series are general type DC signal trigger switches,integrated dustproof?and reversing box, specially for used in DCcordless?brushless?portable power-tools and gardening tools such as: Cordless?brushless?Drills, Cordless?brushless?Screw Drivers, Cordless,Rotary Hammers, Cordless?brushless?Impact Wrenches,Cordless?brushless?grass trimmer, Cordless?brushless?blowers,etc.
產品特征Features
◆可選帶以下功能或附件:
→信號通斷帶電位器輸出功能
→信號通斷帶正反轉信號和電位器輸出功能
→信號通斷帶正反轉霍爾信號和電位器輸出功能
→霍爾信號通斷帶正反轉霍爾信號和霍爾電位器輸出功能
→可選帶閉合鎖定
→帶軟膠扳機
◆Optional with the function or accessory as follows:.
→On-off with linear potentiometer
→On-off with Reversing Signal and linear potentiometer output
→On-off with Reversing Hall Signal and linear potentiometer output
→Optional with Lock-on button
→Trigger covered with rubber (overmolding)
技術數據Technical data
→機械耐久壽命 Mechanical life endurance≥1E5
→電氣耐久壽命 Electrical life endurance≥5E4
→最大電流 Max. current0.1A
→接觸電阻 Contact resistance≤30m Ohm
→絕緣電阻 Insulation resistance≥7M Ohm
→基本介電強度 Dielectric strength of function1500V
→加強介電強度 Dielectric strength of reinforced3000V
→環境溫度 Ambient temperature0°C~55°C
→阻燃等級 FlammabilityUL 94V-0
→防護等級 Protection typeIP40
◆開關內部電子部分在相應使用中一并做過相關測試,本開關適合做二類器具開關使用.
◆The electronics in the switches had to be tested together with the corresponding appliances, so the switches are suitable for appliance of class II.
端子類型Terminals
◆輸入端/輸出端 Input side/Output side:
→帶插頭導線 Wire terminal with Plug
★本產品榮獲實用新型專利，專利號：ZL201922328152.5
★Utility Model patented with the no. is?ZL201922328152.5
電氣參數和認證 Electric Rating and Certification
