DRK-K-A18

DRK防塵直流信號扳機開關

DRK series Dustproof DC Signal Trigger Switches

產品描述Product description

DRK系列是一款專用型的直流信號扳機開關,集成防塵(防水)功能,是為直流無刷充電式電動工具和園林工具特別設計的,可適用于:無刷充電式電鉆、無刷充電式電錘、無刷充電式螺絲起子、無刷電式?jīng)_擊扳手、無刷充電式吹吸機等。
DRK series are one special type DC signal trigger switches, integrated dustproof (and waterproof), designed specially for used in Brushless DC power-tools or Gardening Tools such as: Brushless Cordless Drills, Brushless Cordless Hammers, Brushless Cordless Screw Drivers, Brushless Cordless Impact Wrenches, Brushless Cordless Blowers, etc.

產品特征Features

◆本開關結構緊湊,可選帶以下功能或附件:
→信號通斷帶電位器輸出功能
→信號通斷帶正反轉信號輸出和電位器輸出功能
→帶軟膠扳機
◆The switches combine compact size, optional with the function or accessories as follows:
→Signal On-off with linear pote ntiometer
→Signal On-off with Reversing and linear potentiometer
→Trigger covered with rubber (overmolding)

技術數據Technical data

→機械耐久壽命 Mechanical life endurance≥1E5
→電氣耐久壽命 Electrical life endurance≥5E4
→最大電流 Max. current at 130Vd.c0.1A
→接觸電阻 Contact resistance≤30m Ohm
→絕緣電阻 Insulation resistance≥7M Ohm
→基本介電強度 Dielectric strength of function500V
→加強介電強度 Dielectric strength of reinforced500V
→環境溫度 Ambient tempe rature0°C~55°C
→阻燃等級 FlammabilityUL 94V-0
→防護等級 Protection typeMax.?IP65/IP67
→開關內部電子部分在相應使用中一并做過相關測試,本開關適合做二類器具開關使用.
→The electronics in the switches are to be tested together with the corresponding appliance, the switches are suitable for appliance of class II.

端子類型Terminals

◆輸入端/輸出端 Input side/Output side:
→帶插頭導線 Wire terminal with Plug
→線路板焊接端子 PCB Solder terminal 1.0×0.6mm
★本產品榮獲實用新型專利,專利號:ZL201821441451.9
★Utility Model patented with the no. is?ZL201821441451.9

電氣參數和認證 Electric Rating and Certification

訂貨信息Ordering Information
