◆DSE系列是一款專用型的直流信號扳機開關，集成防塵功能，是特別為直流無刷充電式電動工具設計的，可適用于：無刷充電式電鉆、無刷充電式電錘、無刷充電式螺絲起子、無刷充電式?jīng)_擊扳手等。 ◆DSE series are one special type DC signal trigger switches, integrated dustproof, designed specially for used in Brushless DC power-tools such as: Brushless Cordless Drills, Brushless Cordless Screw Drivers, Brushless Cordless Impact Wrenches,etc.
產品特征Features
◆可選帶以下功能或附件： →信號通斷帶電位器輸出功能 →信號通斷帶正反轉信號輸出和電位器輸出功能 →信號剎車 →帶軟膠扳機 ◆Optional with the function or accessories as follows: →Signal On-off version with linear potentiometer →Signal On-off version with Reversing and linear potentiometer →Signal Brake →Trigger covered with rubber (overmolding)
技術數據Technical data
→機械耐久壽命 Mechanical life endurance≥5E4 →電氣耐久壽命 Electrical life endurance≥1E4 →最大電流 Max. current at 42Vd.c0.1A →接觸電阻 Contact resistance≤30m Ohm →絕緣電阻 Insulation resistance≥7M Ohm →基本介電強度 Dielectric strength of function500V →加強介電強度 Dielectric strength of reinforced500V →環境溫度 Ambient temperature0°C~55°C →阻燃等級 FlammabilityUL 94V-0 →防護等級 Protection typeIP40
◆開關內部電子部分在相應使用中--并做過相關測試,本開關適合做二類器具開關使用.
◆The electronics in the switches had to be tested together with the corresponding appliances, so the switches are suitable for appliance of class II.
端子類型Terminals
◆輸入端/輸出端 Input side/Output side: →導線端子 Wire terminal →帶插頭導線端子 Wire terminal with Plug ★本產品榮獲實用新型專利，專利號：ZL202122394665.3 ★Utility Model patented with the no. is ZL202122394665.3
電氣參數和認證 Electric Rating and Certification
訂貨信息Ordering Information
