產品描述Product description
◆FA01系列是一款通用型的直流扳機調速開關，集成防塵和機械剎車接點，可選帶換向盒，應用于各類直流充電式手持電動工具，如：充電式電鉆、充電式螺絲起子等，也可用于充電式鉆骨機、充電式胸骨鋸、充電式擺鋸等直流醫療器械。
◆FA01 series are one general type DC variable speed trigger switches, integrated dustproof and mechanical brake contact, optional with reversing box, for used in DC cordless portable power-tools such as: Cordless Drills, Cordless Screw Drivers, etc. Also special for used in DC medical tools, such as Cordless Bone Drills, Cordless Sternum Saws, Cordless Overhaul Saws, etc.
產品特征Features
◆可選帶以下功能 Optional with the function as follows:
→電子調速功能 Electronics Speed Control function
→通斷功能 On-off version
→通斷功能帶電位器輸出 On-off with linear potentiometer output
◆可選帶以下附件功能 Optional with the accessories as follows:
→MOS管散熱片 Heatsink for MOSFET
→包軟膠扳機Trigger covered with rubber (Overmolding)、
技術數據Technical data
→機械耐久壽命 Mechanical life endurance≥5E4
→電氣耐久壽命E lectrical life endurance≥1E4
→最大電流 Max.current at 36Vd.c16A
→接觸電阻 Contact resistance≤30m Ohm
→絕緣電阻 Insulation resistance≥7M Ohm
→基本介電強度 Dielectric strength of function500V
→加強介電強度 Dielectric strength of reinforced500V
→環境溫度 Ambient temperature0°C~55°C
→阻燃等級 FlammabilityUL 94V-0
→防護等級 Protection typeIP40
◆開關內部電子部分在相應使用中一并做過相關測試，本開關適合做二類器具開關使用.
◆The electronics in the switches had to be tested together with the corresponding appliances, so the switches are suitable for appliance of class II.
端子類型Terminals
◆輸入端/輸出端 Input side/ Output side:
→插入式端子 Push-in terminal
→導線端子 Wire terminal
電氣參數和認證 Electric Rating and Certification
