FA1-6E-A5S-T4

FA1-6E防塵快速動作扳機開關

FA1-6E series Dust-proof Snap-action Trigger Switches

產品描述Product description

◆FA1-6E系列是一款通用型的扳機開關，集成防塵功能，內部為快速動作結構，廣泛應用于各類手持式電動工具，如：電鉆、電錘、往復鋸、曲線鋸、角向磨光機、攪拌器、型材切割機、石材切割機、電圓鋸、電木銑、砂帶機、砂光機、電刨、電動噴槍、電動釘槍，也可應用于電動園林工具，如：打草機、電鏈鋸、電動割草機、電動掃雪機等。
◆FA1-6E series are general type trigger switches, integrated dustproof, with snap-action structure, commonly for used in portable power tools such as Electric Drills, Rotary Hammers, Reciprocating Saws, Jig Saws, Angle Grinders, Electric Mixers,Cut-Off Machines, Marble Cutters, Electric Routers, Circular Saws, Belt Sanders, Orbit Sanders, Polishers, Electric Planers, Electric Sprayers, Electric Nailers, etc. Besides, they are also suitable for power gardening tools, such as Grass Trimmers, Electric Chain Saws, Electric L awnmowers, Electric Snowthrowers, etc.

產品特征Features

◆可選帶以下鎖定類型 Optional with following lock types:
→無鎖定 No Lock
→閉合鎖定 Lock-on
→斷開鎖定 Lock-off
◆可選帶以下附件 Optional with the accessories as follows:
→包軟膠扳機 Trigger covered with rubber (overmolding)

技術數據Technical data

→機械耐久壽命 Mechanical life endurance≥5E4/1E5
→電氣耐久壽命 Electrical life endurance≥1E4/5E4
→最大沖擊電流 Max. Inrush current at 250V72A
→最大沖擊電流 Max. Inrush currentat 125V108A
→接觸電阻 Contact resistance≤30m Ohm
→絕緣電阻 Insulation resistance≥7M Ohm
→基本介電強度 Dielectric strength of function1500V
→加強介電強度 Dielectric strength of reinforced3000V
→環境溫度 Ambient temperature0°C~55°C
→阻燃等級 FlammabilityUL 94V-0<
→防護等級 Protection typeIP40
→適用于II類防護器具 Suitable for appliances of protection class II

端子類型Terminals

◆輸入端 Input side:
→2×接線柱端子 Pillar terminals φ=2.8mm
◆輸出端 Output side:
→插片端子 Plug- in terminals 6.3×0.8mm
→插片端子 Plug-in terminals 4.8×0.8mm
→插片端子 Plug-in terminals 2.8×0.8mm
