FA1-6H-12-SA13

FA1-6H（防塵)高額定值直流扳機開關

FA1-6H series (Dustproof) High Rated DC Trigger Switches

產品描述Product description

◆FA1-6H系列是一款通用型的高額定扳機開關，有集成防塵功能主體，特別適用于直流電動工具和園林工具，如：直流電圓鋸、直流電鏈鋸、直流電動割草機、直流電動掃雪機等。
◆FA1-6H series are general type high rated trigger switch, have integrated dustproof version, special for used in DC power-tools and gardening tools such as DC Circular Saws, DC Electric Chain Saws, DC Electric Lawnmowers, DC Electric Snowthrowers, etc.

產品特征Features

◆可選帶以下功能類型 Optional with following function types:
→單極常開 Single Pole Normally Open (SPNO)
→單極雙擲 Single Pole Double Throw (SPDT)
→一極常閉，另一極常開
One Pole Normally Open, the other Normally Close

技術數據Technical data

→機械耐久壽命 Mechanical life endurance≥1E5
→電氣耐久壽命 Electrical life endurance≥5E4
→最大沖擊電流 Max. Inrush current at 250V90A
→最大沖擊電流 Max. Inrush current at 125V120A
→接觸電阻 Contact resistance≤30m Oh m
→絕緣電阻 Insulation resistance≥7M Ohm
→基本介電強度 Dielectric strength of function1500V
→加強介電強度 Dielectric strength of reinforced3000V
→環境溫度 Ambient temperature0°C~55°C
→阻燃等級 FlammabilityUL 94V-0
→防護等級 Protection typeIP40
→適用于II類防護器具 Suitable for appliances of protection class II

端子類型Terminals

◆輸入端/輸出端 Input side/ Output side:
→焊接端子 Soldering terminals

產品描述

Product description

產品特征

Features

技術數據

Technical data

端子類型

Terminals

電氣參數和認證

Electric Rating and Certification

訂貨信息

Ordering Information
