產品描述Product description
◆FA2-6AN系列是一款通用型的扳機開關，為FA2-6A系列的防塵改進款，廣泛應用于各類手持式電動工具和園林工具，如：電鉆、云石機、電圓鋸、電木銑、砂帶機、砂光機、電刨、電鏈鋸等。
◆FA2-6AN series are one general type trigger switch, which is dustproof improved version of FA2-6A series, commonly for used in portable power tools and gerdening tools such as Electric Drills, Marble Cutters, Circular Saws, Electric Routers, Belt Sanders, Electric Planers, Electric Chain Saw, etc.
產品特征Features
◆可選帶以下功能 Optional with following function:
→單極常開 SPNO
→一極常開，另一極直通 One Pole NO, the other Connected
◆可選帶以下鎖定類型 Optional with following lock types:
→無鎖定 No Lock
→閉合鎖定 Lock-on
→斷開鎖定 Lock-off
技術數據Technical data
→機械耐久壽命 Mechanical life endurance≥1E5
→電氣耐久壽命 Electrical life endurance≥5E4
→最大沖擊電流 Max. Inrush current at 250V60A
→最大沖擊電流 Max. Inrush current at 125V96A
→接觸電阻 Contact resistance≤30m Ohm
→絕緣電阻 Insulation resistance≥7M? Ohm
→基本介電強度 Dielectric strength of function1500V
→加強介電強度 Diele ctric strength of reinforced3000V
→環境溫度 Ambient temperature0°C~55°C
→阻燃等級 FlammabilityUL 94V-0
→防護等級 Protection typeIP50
→適用于II類防護器具 Suitable for appliances of protection class II
端子類型Terminals
◆輸入端/輸出端 Input side/Output side:
→螺釘端子 Screw terminals M3.5
電氣參數和認證 Electric Rating and Certification
