產品描述Product description
◆FA2-6B系列是一款通用型的扳機開關，集成防塵功能，廣泛應用于各類電動工具，如：型材切割機、斜切鋸、電圓鋸、電錘等。
◆FA2-6B series are one general type trigger switch, integrated dust-proof, commonly for used in power tools such as Cut-off Machines, Miter Saws, Circular Saws, Electric Hammers, etc.
產品特征Features
◆可選帶以下功能 Optional with following function:
→單極常開 SPNO
→單極雙擲 SPDT
→一極常開，另一極直通 One Pole NO, the other Directly
→一極雙擲，另一極直通 One Pole DT, the other Directly
◆可選帶以下附件 Optional with the accessories as follows:
→包軟膠扳機 Trigger covered with rubber (overmolding)
技術數據Technical data
→機械耐久壽命 Mechanical life endurance≥1E5
→電氣耐久壽命 Electrical life endurance≥5E4
→最大沖擊電流 Max. Inrush current at 250V60A
→最大沖擊電流 Max. Inrush current at 125V90A
→接觸電阻 Contact resistance≤30m Ohm
→絕緣電阻 Insulation resistance≥7M Ohm
→基本介電強度 Dielectric strength of function1500V
→加強介電強度 Dielectric strength of reinforced3000V
→環境溫度 Ambient temperature0°C~55°C
→阻燃等級 FlammabilityUL 94V-0
→防護等級 Protection typeIP40
→適用于II類防護器具 Suitable for appliances of protection class II
端子類型Terminals
◆輸入端/輸出端 Input side/Output side:
→接線柱端子 Pillar terminals φ=3.0mm
電氣參數和認證 Electric Rating and Certification
