FA2-6CN-21Y

FA2-6CN防塵扳機開關

FA2-6CN series Dustproof Trigger Switches

產品描述Product description

◆FA2-6CN系列是一款通用型的扳機開關，為FA2-6C系列的防塵改進款，廣泛應用于各類電動工具，如：型材切割機、斜切鋸、云石機、電圓鋸、電錘、電木銑、砂帶機、砂光機、電刨等。
◆FA2-6CN?series are one general type trigger switches, which is?dustproof improved version?of?FA2-6C?series, commonly for used in power tools such as Cut-off Machines, Miter Saws, Marble Cutters, Circular Saws, Electric Hammers, Electric Routers, Belt Sanders, Electric Planers, etc.

產品特征Features

◆可選帶以下功能 Optional with following function:

→單極常開 SPNO

→單極雙擲 SPDT

→雙極常開 DPNO

→雙極雙擲 DPDT
→一極常開，另一極常閉 One Pole NO, the other NC
→一極常開，另一極雙擲 One Pole NO, the other DT
◆可選帶以下鎖定類型 Optional with following lock types:
→無鎖定 No Lock
→閉合鎖定 Lock-on
→斷開鎖定 Lock-off

技術數據Technical data

→機械耐久壽命 Mechanical life endurance≥1E5
→電氣耐久壽命 Electrical life endurance≥5E4
→最大沖擊電流 Max. Inrush current at 250V60A
→最大沖擊電流 Max. Inrush current at 125V96A
→接觸電阻 Contact resistance≤30m Ohm
→絕緣電阻 Insulation resistance≥7M Ohm
→基本介電強度 Dielectric strength of function1500V
→加強介電強度 Dielectric strength of reinforced3000V
→環境溫度 Ambient temperature0°C~55°C
→阻燃等級 FlammabilityUL 94V-0
→防護等級 Protection typeIP50
→適用于II類防護器具 Suitable for appliances of protection class II

端子類型Terminals

◆輸入端/輸出端 Input side/Output side:
→接線柱端子 Pillar terminals φ=3.0mm
