產品描述Product description
◆FA2-6D, DX, DY系列是一款通用型的扳機開關，可選集成防塵功能，廣泛應用于各類電動工具，如：云石機、電圓鋸、電錘、電木銑、砂帶機、帶鋸機、砂光機、電刨、攪拌器、電動噴槍等。
◆FA2-6D, DX, DY?series are one general type trigger switch,?optional integrated dustproof version, commonly for used in power tools such as Marble Cutters, Circular Saws, Electric Hammers, Electric Routers, Belt Sanders, Belt Saws, Electric Planers, Electric Mixers, Electric Sprayers, etc.
產品特征Features
◆可選帶以下功能 Optional with following function:
→雙極常開 DPNO
→單極常開 SPNO
◆可選帶以下鎖定類型 Optional with following lock types:
→無鎖定 No Lock
→閉合鎖定 Lock-on
→斷開鎖定 Lock-off
技術數據Technical data
→機械耐久壽命 Mechanical life endurance≥1E5
→電氣耐久壽命 Electrical life endurance≥5E4
→最大沖擊電流 Max. Inrush current at 250V48A
→最大沖擊電流 Max. Inrush current at 125V96A
→接觸電阻 Contact resistance≤30m Ohm
→絕緣電阻 Insulation resistance≥7M? Ohm
→基本介電強度 Dielectric strength of function1500V
→加強介電強度 Dielectric strength of reinforced3000V
→環境溫度 Ambient temperature0°C~55°C
→阻燃等級 FlammabilityUL 94V-0
→防護等級 Protection typeIP40
→適用于II類防護器具 Suitable for appliances of protection class II
端子類型Terminals
◆輸入端 Input side:
→接線柱端子 Pillar terminals φ=3mm
→插入式端子可插入沾錫導線，帶插片端子導線或銅包頭導線
→Push-in terminals for soldered strands, strands with end sleeve
◆輸出端 Output side:
→插入式端子可插入沾錫導線，帶插片端子導線或銅包頭導線
→Push-in terminals for soldered strands, strands with end sleeve or strands with end claws
電氣參數和認證 Electric Rating and Certification
