FA7-10A-A9

FA7-10A,F(xiàn)A7-10B(防塵)快速動作扳機開關

FA7-10A, FA7-10B series (Dustproof) Snap-action Trigger Switches

產品描述Product description

FA7-10系列是一款通用型的扳機開關,內部為快速動作結構,可選內部集成防塵功能,應用于對防塵要求較低的電動工具和園林工具,如:攪拌器、電圓鋸、曲線鋸、拋光機、電刨、電錘、電鎬、型材切割機、斜切鋸、電鏈鋸、電動割草機等。
FA7-10?series are one general type trigger switch,?with snap-action structure,?optional integrated dustproof, for used in power-tools and gardening tools such as Electric Mixers, Circular Saws,Jig Saws, Polishers Grinders, Electric Planers, Rotary Hammers,?Demolition Hammers, Miter Saws, Cut-off Machines, Electric Chain Saws, Electric Lawnmowers, etc.

產品特征Features

◆可選帶以下鎖定類型 Optional with following lock types:
→無鎖定 No Lock
→閉合鎖定 Lock-on
→斷開鎖定 Lock-off
◆可選帶以下功能或附件?Optional with following function or accessories:
→雙極常開 DPNO
→單極常開 SPNO
→一極常開,另一極常閉?One Pole Normally Open, the other normally close
→帶軟膠扳機 Trigger covered with rubber (Overmolding)

技術數據Technical data

→機械耐久壽命 Mechanical life endurance≥1E5
→電氣耐久壽命 Electrical life endurance≥5E4
→最大沖擊電流 Max. Inrush current at 250V90A
→最大沖擊電流 Max. Inrush current at 127V120A
→接觸電阻 Contact resistance≤30m Ohm
→絕緣電阻 Insulation resistance≥7M  Ohm
→基本介電強度 Dielectric strength of function1500V
→加強介電強度 Dielectric strength of reinforced3000V
→環境溫度 Ambient temperature0°C~55°C
→阻燃等級 FlammabilityUL 94V-0
→防護等級 Protection typeIP40
→適用于II類防護器具 Suitable for appliances of protection class II

端子類型Terminals

◆輸入端/輸出端Input side/Output side:
→接線柱端子Pillar terminals φ =3.5mm
★本產品榮獲實用新型專利,專利號:ZL201920475212.3
★Utility Model patented with the no. is?ZL201920475212.3

電氣參數和認證 Electric Rating and Certification

訂貨信息Ordering Information
