FA7-10D-A0-B4

FA7-10D扳機開關

FA7-10D series Trigger Switches

產品描述Product description

FA7-10D系列是一款通用型的扳機開關,應用于對防塵要求較低的手持式電動工具和園林工具,如:攪拌器、電動釘槍、電圓鋸、打草機、電鏈鋸、電動割草機、電動掃雪機等。
FA7-10D series are general type trigger switch, for used in portable power-tools and gardening tools such as Electric Mixers, Electric Nailers, Grass Trimmers, Circular Saws, Electric Chain Saws, Electric Lawnmowers, Electric Snowthrowers, etc.

產品特征Features

◆可選帶以下鎖定類型 Optional with following lock types:
→無鎖定 No Lock
→閉合鎖定 Lock-on
→斷開鎖定 Lock-off

技術數據Technical data

→機械耐久壽命 Mechanical life endurance≥1E5
→電氣耐久壽命 Electrical life endurance≥5E4
→最大沖擊電流 Max. Inrush current at 250V90A
→最大沖擊電流 Max. Inrush current at 125V108A
→接觸電阻 Contact resistance≤30m Ohm
→絕緣電阻 Insulation resistance≥7M Ohm
→基本介電強度 Dielectric strength of function1500V
→加強介電強度 Dielectric strength of reinforced3000V
→環境溫度 Ambient temperature0°C~55°C
→阻燃等級 FlammabilityUL 94V-0
→防護等級 Protection typeIP40
→適用于II類防護器具 Suitable for appliances of protection class II

端子類型Terminals

◆輸入端/輸出端 Input side/Output side:
→接線柱端子 Pillar terminals φ=3.5mm

電氣參數和認證 Electric Rating and Certification
