FA1-10A-A3

FA1-10A防塵快速動作扳機開關

FA1-10A series Dustproof Snap-action Trigger Switches

產品描述Product description

FA1-10A 系列是一款通用性的大電流扳機開關,集成防塵功能,內部為快速動作結構,適合大功率的臺式和手持式電動工具,如:型材切割機、斜切鋸(介鋁機)、150、180和230角向磨光機、拋光機、電圓鋸、電錘、電鎬、電鏈鋸等。
FA1-10A series are general type high rated trigger switches,integrated dustproofwith snap-action structure, for used in high rated bench top or portable power-tools such as Cut-off Machines,Miter Saws, 150mm, 180mm and 230mm Large Angle Grinders, Polishers, Circular Saws, Rotary Hammers, Demolition Hammers, Electrics Chain Saws, etc.

產品特征Features

◆可選帶以下功能 Optional with following function:
→雙極常開 Double Pole Normally Open (DPNO)
→一極常開,另一極常閉 One Pole Normally Open, the other Normally Close
→單極雙擲(常閉常開) (用極間連接片實現)
Single Pole Double Throw (SPDT)(with pole joint)
◆可選帶以下附件 Optional with following accessories:
→帶軟膠扳機 Trigger covered with rubber (Overmolding)
→剎車連接片 Connection Piece for brake
◆可選帶以下鎖定類型 Optional with following lock types:
→無鎖 No Lock
→閉合鎖定 Lock-on
→斷開鎖定 Lock-off
→斷開鎖定帶閉合鎖定 Lock-off with lock-on

技術數據Technical data

→機械耐久壽命 Mechanical life endurance≥1E5
→電氣耐久壽命 Electrical life endurance≥5E4
→最大沖擊電流 Max. Inrush current at 250V90A
→最大沖擊電流 Max. Inrush current at 125V132A
→接觸電阻 Contact resistance≤30m Ohm
→絕緣電阻 Insulation resistance≥7M  Ohm
→基本介電強度 Dielectric strength of function1500V
→加強介電強度 Dielectric strength of reinforced3000V
→環境溫度 Ambient temperature0°C~55°C
→阻燃等級 FlammabilityUL 94V-0
→防護等級 Protection typeIP40
→適用于II類防護器具 Suitable for appliances of protection class II

端子類型Terminals

◆輸入端/輸出端 Input side/Output side:
→4×螺釘端子 Screw terminals M4 or M3.5

電氣參數和認證 Electric Rating and Certification

訂貨信息Ordering Information
