FA5-10A-A8

FA5-10A防塵快速動作扳機開關

FA5-10A series Dustproof Snap-action Trigger Switches

產品描述Product description

FA5-10A, FA5-10B系列是一款通用性的扳機開關,集成防塵功能,內部為快速動作結構,適合一般功率的電動工具,如:型材切割機、斜切鋸(介鋁機)、125和150角磨機、電錘、電鎬等。
FA5-10A, FA5-10B series are one general type trigger switch, integrated dustproof, with snap-action structure, for used in portable or bench top power-tools such as Cut-off Machines, Miter Saws, 125mm and 150mm Angle Grinders, Rotary Hammers, Demolition Hammers, etc.

產品特征Features

◆有多種支架和扳機可選 Optional with different supports and triggers
◆可選帶以下鎖定類型 Optional with following lock types:
→無鎖 No Lock
→閉合鎖定 Lock-on
→斷開鎖定 Lock-off

技術數據Technical data

→機械耐久壽命 Mechanical life endurance≥1E5
→電氣耐久壽命 Electrical life endurance≥5E4
→最大沖擊電流 Max. Inrush current at 250V60A
→最大沖擊電流 Max. Inrush currentat 125V90A
→接觸電阻 Contact resistance≤30m Ohm
→絕緣電阻 Insulation resistance≥7M  Ohm
→基本介電強度 Die lectric strength of function1500V
→加強介電強度 Dielectric strength of reinforced3000V
→環境溫度 Ambient temperature0°C~55°C
→阻燃等級 FlammabilityUL 94V-0
→防護等級 Protection typeIP40
→適用于II類防護器具 Suitable for appliances of protection class II

端子類型Terminals

◆輸入端/輸出端 Input side/Output side:
→螺釘端子 Screw terminals M4

電氣參數和認證 Electric Rating and Certification

訂貨信息Ordering Information
