FA5-10C-A0

FA5-10C防塵快速動作扳機開關

FA5-10C series Dustproof Snap-action Trigger Switches

產品描述Product description

◆FA5-10C 系列是一款專用型的扳機開關，集成防塵功能，適合一般功率的臺式和手持式電動工具及園林工具，如：型材切割機、斜切鋸(介鋁機)、125、150和180角向磨光機、拋光機、電圓鋸、電錘、電鎬、電鏈鋸等。
◆FA5-10C series are general type trigger switches, integrated dustproof, for used in portable or bench top power-tools such as Cut-off Machines, Miter Saws, 125mm, 150mm and 180mm Angle Grinders, Circular Saws, Polishers, Rotary Hammers, Demolition Hammers, Electric Chain Saws, etc.

產品特征Features

◆可選帶以下鎖定類型 Optional with following lock types:
→無鎖定 No Lock

→閉合鎖定 Lock-on

→斷開鎖定 Lock-off

技術數據Technical data

→機械耐久壽命 Mechanical life endurance≥1E5
→電氣耐久壽命 Electrical life endurance≥5E4
→最大沖擊電流 Max. Inrush current at 250V90A
→最大沖擊電流 Max. Inrush current at 127V120A
→接觸電阻 Contact resistance≤30m Ohm
→絕緣電阻 Insulation resistance≥7M Ohm
→基本介電強度 Dielectric strength of function1500V
→加強介電強度 Dielectric strength of reinforced3000V
→環境溫度 Ambient temperature0°C~55°C
→阻燃等級 FlammabilityUL 94V-0
→防護等級 Protection typeIP40
→適用于II類防護器具 Suitable for appliances of protection class II

端子類型Terminals

◆輸入端/輸出端 Input side/Output side:
→螺釘端子 Screw terminals M4
