產品描述Product description
◆FA7-6J系列是一-款專用型的按鈕開關，應用于手持式電動工具或小家電，如：電動釘槍、電吹風等。
◆FA7-6J series are special type push-button switch, for used in portable power tools or small appliances such as Electric Tackers, Hair Driers, etc.
產品特征Features
◆可選帶以下功能 Optional with the function as follows:
→單極常開 SPNO (Single Pole Normally Open)
→單極雙擲 SPDT (Single Pole Double Throw)
→單極常閉 SPNC (Single Pole Normally Close)
技術數據Technical data
→機械耐久壽命 Mechanical life endurance≥5E4/1E5
→電氣耐久壽命 Electrical life endurance≥1E4/5E4
→最大電流 Max. current at 250V10A
→最大電流 Max. current at 125V16A
→接觸電阻 Contact resistance≤30m Ohm
→絕緣電阻 Insulation resistance≥7M Ohm
→基本介電強度 Dielectric strength of function1500V
→加強介電強度 Dielectric strength of reinforced3000V
→環境溫度 Ambient temperature0°C~85°C;
→阻燃等級 FlammabilityUL 94V-0
→防護等級 Protection typeIP40
→適用于II類防護器具 Suitable for appliances of protection class II
端子類型Terminals
◆輸入端/輸出端 Input side/Output side:
→焊接端子 Soldering terminals
電氣參數和認證 Electric Rating and Certification
