產品描述Product description
◆FA7-6K系列是一款專用型的按鈕開關，應用于各類家用電器和園林工具，如：自動掃地機、智能自動割草機等。
◆FA7-6K series are special type push-button switch, commonly for used in home appliances or gardening tools such as Automatic Vacuum Cleaners, Smart Automatic Lawnmovers, etc.
產品特征Features
◆可選帶以下功能 Optional with following function:
→單極信號常開 Signal Single Pole Normally Open (SSPNO)
→雙極信號常開 Signal Double Pole Normally Open (SDPNO)
→單極常開帶霍爾信號輸出 SPNO with Hall Signal
→雙極常開帶霍爾信號輸出 DPNO with Hall Signal
→帶防護罩可實現防塵防水功能 Optional with Protection Cap for dustproof and waterproof
技術數據Technical data
→機械耐久壽命 Mechanical life endurance≥3E6
→電氣耐久壽命 Electrical life endurance≥3E6
→最大電流 Max. current at 5Vd.c10mA
→接觸電阻 Contact resistanceN/A
→絕緣電阻 Insulation resistanceN/A
→基本介電強度 Dielectric strength of functionN/A
→加強介電強度 Dielectric strength of reinforcedN/A
→環境溫度 Ambient temperature-25°C~85°C
→阻燃等級 FlammabilityUL 94V-0
→防護等級 Protection typeIP65
→適用于II類防護器具 Suitable for appliances of protection class II
端子類型Terminals
◆輸入端/輸出端 Input side/Output side:
→導線端子 Wire terminals
→帶插頭導線端子 Wire terminals with Plug
電氣參數和認證 Electric Rating and Certification
