◆FDC系列是一款專用型的倒扳開關，也叫搖桿開關或撥動開關，應用于各類電動工具，如：電木銑、臺式砂輪機等。 ◆FDC series are one special type Lever switch, for used in power-tools such as Routers, Bench Grinders, etc.
產品特征Features
◆可選帶以下功能 Optional with following function: →單極單擲 SPST (Single Pole Single Throw) →單極雙擲 SPDT (Single Pole Double Throw)
技術數據Technical data
→機械耐久壽命 Mechanical life endurance≥1E5 →電氣耐久壽命 Electrical life endurance≥5E4 →最大沖擊電流 Max.Inrush current at 250V60A →最大沖擊電流 Max.Inrush current at 127V96A →接觸電阻 Contact resistance≤30m Ohm →絕緣電阻 Insulation resistance≥7M Ohm →基本介電強度 Dielectric strength of function1500V →加強介電強度 Dielectric strength of reinforced3000V →環境溫度 Ambient temperature0°C~55°C →阻燃等級 FlammabilityUL 94V-0 →防護等級 Protection typeIP40 →適用于II類防護器具 Suitable for appliances of protection class II
