◆FDD系列是一款專用型的滑動開關，也叫推拉開關或推撥開關，應用于各類電動工具和園林工具，如：電木銑、吹吸機等。
◆FDD series are special type slide switches, for used in power-tools or gardening tools such as Routers, Blowers, etc.
產品特征Features
◆可選帶兩種不同金屬外殼 Optional with different shell
技術數據Technical data
→機械耐久壽命 Mechanical life endurance≥1E5
→電氣耐久壽命 Electrical life endurance≥5E4
→最大沖擊電流 Max.Inrush current at 250V48A
→最大沖擊電流 Max.Inrush current at 125V48A
→接觸電阻 Contact resistance≤30m Ohm
→絕緣電阻 Insulation resistance≥7M Ohm
→基本介電強度 Dielectric strength of function1500V
→加強介電強度 Dielectric strength of reinforced3000V
→環境溫度 Ambient temperature0°C~55°C
→阻燃等級 FlammabilityUL 94V-0
→防護等級 Protection typeIP40
→適用于II類防護器具 Suitable for appliances of protection class II
