FDJ-1306

FDJ, FDM滑動(推拉)開關

FDJ, FDM series Slide (Push-pull) Switches

產品描述Product description

◆FDJ, FDM系列是迷你型的小型推拉開關，也叫滑動開關，應用于各類需要微電流檔位控制的電器，如：迷你型螺絲起子、充電燈等。
◆FDJ, FDM series are mini type slide switches, commonly for used in micro current appliances such as Mini Screwdrivers, Rechargeable Lights, etc.

技術數據Technical data

→機械耐久壽命 Mechanical life endurance≥5E4
→電氣耐久壽命 Electrical life endurance≥1E4
→最大電流 Max. current6A
→接觸電阻 Contact resistance≤30m Ohm
→絕緣電阻 Insulation resistance≥7M Ohm
→基本介電強度 Dielectric strength of function500V
→加強介電強度 Diele ctric strength of reinforced500V
→環境溫度 Ambient temperature0°C~85°C
→阻燃等級 FlammabilityUL 94V-0
→防護等級 Protection typeIP40
→適用于II類防護器具 Suitable for appliances of protection class II

端子類型Terminals

◆輸入端/輸出端 Input side/Output side:
→焊接端子 Soldering terminals φ=1.2mm
→線路板焊接端子 PCB Soldering terminals 1.0×0 8mm

電氣參數和認證 Electric Rating and Certification
