FDK-2410

FDK滑動(推拉)開關

FDK series Slide (Push-pull) Switches

產品描述Product description

◆FDK系列是一款通用型的推拉開關，也叫滑動開關，廣泛應用于各類需要檔位控制的電動工具和小家電，如：熱風槍、電吹風等。
◆FDK series are general type slide switches, commonly for used in power-tools and small home appliances such as Heat Guns, Hair Drvers, etc.

技術數據Technical data

→機械耐久壽命 Mechanical life endurance≥5E4
→電氣耐久壽命 Electrical life endurance≥1E4
→最大電流 Max. current at 250V10A
→接觸電阻 Contact resistance≤30m Ohm
→絕緣電阻 Insulation resistance≥100M  Ohm
→基本介電強度 Dielectric strength of function500V
→加強介電強度 Dielectric strength of reinforced500V
→環境溫度 Ambient temperature0°C~85°C
→阻燃等級 FlammabilityUL 94V-0
→防護等級 Protection typeIP40
→適用于II類防護器具 Suitable for appliances of protection class II

端子類型Terminals

◆輸入端/輸出端 Input side/Output side:
→焊接端子S oldering terminals φ=2.0mm

電氣參數和認證 Electric Rating and Certification

訂貨信息Ordering Information
