產品描述Product description
◆FDPX系列是一款通用型的滑動開關，也叫推拉開關或推撥開關，內部為瞬間動作結構，應用于各類手持電動工具，如：100和125角磨機、多功能工具等。
◆FDPX series are general type slide switches, with snap-action structure, commonly for used in power-tools such as 100mm and 125mm Angle Grinders, Multi-function Tools, etc.
產品特征Features
◆可選帶以下功能 Optional with the following function:
→單極單擲 SPST (Single Pole Single Throw)
→單極雙擲 SPDT (Single Pole Double Throw)
技術數據Technical data
→機械耐久壽命 Mechanical life endurance≥1E5
→電氣耐久壽命 Electrical life endurance≥5E4
→最大沖擊電流 Max. Inrush current at 250V72A
→最大沖擊電流 Max. Inrush current at 127V108A
→接觸電阻 Contact resistance≤30m Ohm
→絕緣電阻 Insulation resistance≥7M Ohm
→基本介電強度 Dielectric strength of function1500V
→加強介電強度 Diele ctric strength of reinforced3000V
→環境溫度 Ambient temperature0°C~55°C
→阻燃等級 FlammabilityUL 94V-0
→防護等級 Protection typeIP40
→適用于II類防護器具 Suitable for appliances of protection class II
端子類型Terminals
◆輸入端/輸出端 Input side/Output side:
→焊接端子 Soldering terminals 3.0×0.8mm
→線路板焊接端子 PCB Soldering terminals 2.6×0.8mm
→線路板焊接端子 PCB Soldering terminals 1.0×0.8mm
★本產品榮獲實用新型專利，專利號：ZL202021714438.3
★Utility Model patented with the no. is ZL202021714438.3
電氣參數和認證 Electric Rating and Certification
