產品描述Product description
◆JB17系列是一款專用型的滑動開關，也叫推拉開關或推撥開關，集成防塵功能，適用于小型的電動工具，如：砂光機、100mm和125mm角磨機等。
◆JB17 series are one special type slide switches, integratd dustproof, special for low Rated portable Power-tools, such as: Orbit Sanders, 100mm and 125mm Small Angle Grinders, etc.
產品特征Features
◆可選帶以下功能 Optional with the function as follows:
→單極常開 Single Pole Single Throw (SPST)
→單極雙擲 Single Pole Double Throw (SPDT)
技術數據Technical data
→機械耐久壽命 Mechanical life endurance≥1E5
→電氣耐久壽命 Electrical life endurance≥5E4
→最大沖擊電流 Max. Inrush current at 250V36A
→最大沖擊電流 Max. Inrush current at 127V60A
→接觸電阻 Contact resistance≤30m Ohm
→絕緣電阻 Insulation resistance≥7M Ohm
→基本介電強度 Diele ctric strength of function1500V
→加強介電強度 Dielectric strength of reinforced3000V
→環境溫度 Ambient temperature0°C~55°C
→阻燃等級 FlammabilityUL 94V-0
→防護等級 Protection typeIP50
→適用于II類防護器具 Suitable for appliances of protection class II
端子類型Terminals
◆輸入端/輸出端 Input side/Output side:
→插片端子 Plug-in terminals 4.8×0.8mm
→焊接端子 Solder terminals
→線路板焊接端子 PCB Solder terminals
電氣參數和認證 Electric Rating and Certification
