FD2-8GX-B

FD2-8GX(防塵)正反轉倒扳開關

FD2-8GX series (Dustproof) Change-over Lever Switches

產品描述Product description

◆FD2-8GX系列是一款專用型的倒扳開關，也叫搖桿開關或撥動開關，應用于各類手持式電動工具，如：電動沖擊扳手、電動攪拌器、電動葫蘆等。
◆FD2-8GX series are special type Lever switches, also named Toggle switch, commonly for used in portable power-tools such as Electric Wrenches, Electric Mixers, Electric Winches, etc.

產品特征Features

◆可選帶以下功能 Optional with following function:
→雙極單擲 DPST (Double Pole Single Throw)
→雙極雙擲 DPDT (Double Pole Double Throw)

→雙極雙擲帶中間斷開 DPDT with center off

→點動方式 Momentary act

技術數據Technical data

→機械耐久壽命 Mechanical life endurance≥5E4/1E5
→電氣耐久壽命 Electrical life endurance≥1E4/5E4
→最大沖擊電流 Max. Inrush current at 250V72A
→最大沖擊電流 Max. Inrush current at 125V108A
→接觸電阻 Contact resistance≤30m Ohm
→絕緣電阻 Insulation resistance≥7M  Ohm
→基本介電強度 Dielectric strength of function1500V
→加強介電強度 Dielectric strength of reinforced3000V
→環境溫度 Ambient temperature0°C~55°C
→阻燃等級 FlammabilityUL 94V-0
→防護等級 Protection typeIP40
→適用于II類防護器具 Suitable for appliances of protection class II

端子類型Terminals

◆輸入端/輸出端 Input side/Output side:
→插片端子 Plug-in terminals 4.8×0.8mm
→螺釘端子 Screw terminals M3.5

電氣參數和認證 Electric Rating and Certification

訂貨信息Ordering Information
