產品描述Product description
◆FD2-12G系列是一款專用型的倒扳開關，也叫搖桿開關，集成防塵和防水功能，廣泛應用于各類臺式電動工具，如：臺式推拉鋸、臺式圓鋸、臺式刨床、臺式銑床、臺式線鋸、臺式鉆床、臺式車床、臺式砂輪機、臺式瓷磚切割機、地板鋸等。
◆FD2-12G series are special type Lever switches, integrated dustproof and waterproof, commonly for used in bench top power-tools such as Bench Push-pull Saws, Bench Circular Saws, Bench Planers, Bench Routers, Bench Scroll Saws, Drill Presses, Bench lathes, Bench Grinders, Bench Marble Cutters, Floor Cutters, etc.
產品特征Features
◆可選帶以下功能 Optional with following function:
→單極單擲 SPST (Single Pole Single Throw)
→單極雙擲 SPDT (Single Pole Double Throw)
→單極雙擲中間斷開 SPDT with center off
→雙極單擲 DPST (Double Pole Single Throw)
→雙極雙擲 DPDT (Double Pole Double Throw)
→雙極雙擲帶中間斷開 DPDT with center off
◆可選帶以下附件 Optional with following accessory:
→兒童安全鎖 Key for children's safety
技術數據Technical data
→機械耐久壽命 Mechanical life endurance≥1E5/ 5E4
→電氣耐久壽命 Electrical life endurance≥5E4/ 1E4
→最大沖擊電流 Max.Inrush current at 250V90A
→最大沖擊電流 Max.Inrush current at 125V132A
→接觸電阻 Contact resistance≤30m Ohm
→絕緣電阻 Insulation resistance≥7M Ohm
→基本介電強度 Dielectric strength of function1500V
→加強介電強度 Dielectric strength of reinforced3000V
→環境溫度 Ambient temperature0°C~55°C
→阻燃等級 FlammabilityUL 94V-0
→防護等級 Protection typeIP54
→適用于II類防護器具 Suitable for appliances of protection class II
端子類型Terminals
◆輸入端/輸出端 Input side/Output side:
→插片端子 Plug-in terminals 6.3×0.8mm
→插片端子 Plug-in terminals 4.8×0.8mm
→焊接端子 Soldering terminals 4.8×0.8mm
→螺釘端子 Screw terminals M3.5
電氣參數和認證 Electric Rating and Certification
