產品描述Product description
◆K2-1x2系列是一款標準型的蹺板開關,也通稱船型開關、波形開關等,用途極廣,廣泛應用于各類家用電器及辦公設備,如:電扇、飲水機、取暖器等。
◆K2-1x2 series are standard type rocker switches, commonly for use in small Home appliances and office equipments, such as Electric F ans, Drinking Machines, Electric Heaters, etc.
產品特征Features
◆可選帶以下功能 Optional with the function as follows:
→兩極單擲 2PST (2 Pole Single Throw)
→兩極雙擲 2PDT (2 Pole Double Throw)
→兩極雙擲帶中間斷開 2PDT with Centre-off
→點動功能 Momentary act
技術數據Technical data
→機械耐久壽命 Mechanical life endurance≥5E4 / 1E5
→電氣耐久壽命 Electrical life endurance≥1E4 / 5E4
→最大沖擊電流 Max. Inrush current at 250V48A / 72A
→最大沖擊電流 Max. Inrush current at 125V48A / 96A
→接觸電阻 Contact resistance≤30m Ohm
→絕緣電阻 Insulation resistance≥7M Ohm
→基本介電強度 Dielectric strength of function1500V
→加強介電強度 Dielectric strength of reinforced3000V
→環境溫度 Ambient temperature0°C~105°C
→操動件溫度 Actuator temperature0°C~55°C
→阻燃等級 FlammabilityUL 94V-0
→防護等級 Protection typeIP40
→適用于II類防護器具 Suitable for appliances of protection class II
端子類型Terminals
◆輸入端/輸出端 Input side/Output side:
→插片端子 Plug-in terminals 6.3×0.8mm
→插片端子 Plug-in terminals 4.8×0.8mm
→焊接端子 Solder terminals
電氣參數和認證 Electric Rating and Certification
